CASE 2050M
Model 2050M · Engine F4HFE613A / N67
214 HP
Power
20.599 kg
Operating Wt.
1010 Nm
Torque
Informasi Umum
- Merek
- Case
- Model
- 2050M
- Kategori
- Bulldozer
Mesin
- Engine Brand
- FPT (Fiat Powertrain Technologies)
- Engine Type
- F4HFE613A / N67
- Silinder
- 6
- Displacement
- 6700 cc
- Power
- 160 kW
- Power
- 214 HP
- Torque
- 1010 Nm
- Rated RPM
- 2000 rpm
- Turbocharged
- Ya
- Emission Standard
- Tier 3 / Tier 4 Final Equivalent
Berat & Kapasitas
- Operating Weight
- 20599 kg
- Shipping Weight
- 20100 kg
- Ground Pressure
- 37 kPa
Sistem Hidrolik
- Pump Type
- Variable Displacement Axial Piston Pump
- Flow Rate
- 178 L/min
- System Pressure
- 24,8 MPa
- Hydraulic Tank
- 121 L
- Total Hydraulic System
- 160 L
Mobilitas
- Low Speed Travel
- 3,2 km/h
- High Speed Travel
- 9,3 km/h
- Gradeability
- 60 %
- Min Turning Radius
- —
Dimensi
- Length
- 5560 mm
- Width
- 3420 mm
- Height
- 3120 mm
- Ground Clearance
- 460 mm
- Track Width
- 610 mm
- Tail Swing Radius
- —
Kapasitas Fluida
- Fuel Tank
- 405 L
- Engine Oil
- 16,5 L
- Coolant
- 30,2 L
- Hydraulic Tank
- 121 L
- Hydraulic System
- 160 L
- Transmission Oil
- 50 L
Fast Moving Spare Parts
- Engine Oil Filter
- 84228488 / 47135706
- Fuel Filter
- 84565884 & 47458190
- Air Filter (Outer)
- 87682993
- Air Filter (Inner)
- 87682999
- Hydraulic Return Filter
- 84255685
- Hydraulic Pilot Filter
- Tidak ada
- Fan Belt
- 48011284
- Battery
- 12V, 100Ah atau 120Ah sebanyak 2 buah
